Product description
| BST 13500lbs | Technical specifications |
| Pull capacity (single line) | 13500lbs / 6124 kg |
| Motor | 6,7 HP / 4,9 kW |
| Controls | Wired/ wireless remote control |
| Gear | 3-stage planetary |
| Gear ratio | 265:1 |
| Brake | automatic |
| Rope | 26 m x 10 mm |
| Weight | 24,8 kg |
| Dimentions | 535 mm x 160 mm x 251 mm |
| Fairlead | Aluminium hawse fairlead |
| Line speed and motor current (first layer) | ||||||
| Lbs | 0 | 4000 | 6000 | 10000 | 13500 | |
| Line pull | Kg | 0 | 1814 | 2722 | 1150 | 6124 |
| Line speed | M/min | 6,8 | 3,8 | 3 | 2,1 | 1,2 |
| Motor current | Amper | 80 | 170 | 210 | 310 | 420 |
| Line pull and cable capacity | ||||
| Layer of cable | 1 | 2 | 3 | |
| Lbs | 13500 | 11500 | 9600 | |
| Rated line pull per layer | Kg | 6124 | 5216 | 4355 |
| Cable capacity per layer | m | 6 | 13 | 22 |
