Product description
'-
| BST S 12000lbs | Technical specifications | |||
| Pull capacity(single line) | 12000 lbs / 5443 kg | |||
| Motor 12V | 6,0 HP / 4,4 kW | |||
| Controls | Wired / wireless remote control | |||
| Gear | 3-stage planetary | |||
| Gear ratio | 265:1 | |||
| Brake | Automatic | |||
| Rope | 26m x 10 mm | |||
| Fairlead | hawse fairlead | |||
| Net weight | 21 kg | |||
| Mounting bolt pattern | 254mm x 114,3mm 4-M12 | |||
| Dimensions | (L x W x H) 545mm 160mm 194mm | |||
| Line speed and motor current (first layer) | ||||||
| Line pull | Lbs | 0 | 4000 | 6000 | 10000 | 12000 |
| Kg | 0 | 1814 | 2722 | 4536 | 5443 | |
| Line speed | M/min 12V | 6,8 | 3,8 | 3 | 2,1 | 1,7 |
| Motor current | Amper 12V | 80 | 170 | 210 | 310 | 360 |
| Line pull and cable capacity | ||||||
| Layer of cable | 1 | 2 | 3 | 4 | ||
| Rated line pull per layer | Lbs | 12000 | 9900 | 8300 | 7000 | |
| Kg | 5443 | 4490 | 3765 | 3175 | ||
| Cable capacity per layer | M | 6 | 13 | 22 | 25 | |
