Product description
| EN 14492-1 BST 13500lbs | Technical specifications |
| Pull capacity (single line) | 13500 lbs/6123 |
| Motor | kW; 7,5KM/5,5 kW |
| Controls | Wired/wireless remote control |
| Gear | 3-stage planetary |
| Gear ratio | 450:1 |
| Barke | automatic |
| Rope | 30 m x 11 mm |
| Weight | 78 kg |
| Dimentions | 590 mm x 226 mm x 265 mm |
| Fairlead | 4-ways rollers fairlead |
| Mounting bolt pattern | 254 mm x 114,3 4-M12 |
| Line speed and motor current (first layer) | ||||||
| lbs | 0 | 4000 | 6000 | 10000 | 13500 | |
| Line pull | kg | 0 | 1814 | 2722 | 4536 | 6123 |
| Line speed | M/min 24V | 4,9 | 2,2 | 1,8 | 1,7 | 1,4 |
| Motor current | Amper 24V | 48 | 140 | 191 | 235 | 280 |
| Line pull and cable capacity | |||||
| Layer of cable | 1 | 2 | 3 | 4 | |
| lbs | 13500 | 9900 | 8300 | 7000 | |
| Rated line pull per layer | kg | 6123 | 4490 | 3765 | 3175 |
| Cable capacity per layer | m | 6 | 13 | 21 | 28,5 |
