Product description
| BST 10000lbs | Technical specifications |
| Pull capacity (single line) | 10000lbs / 4536 kg |
| Motor | 5,5 HP / 4 kW |
| Controls | Wired/ wireless remote control |
| Gear | 3-stage planetary |
| Gear ratio | 218:1 |
| Brake | automatic |
| Rope | 28 m x 8 mm |
| Weight | 34,6 kg |
| Dimentions | 535 mm x 160 mm x 218 mm |
| Fairlead | 4-ways rollers fairlead |
| Line speed and motor current (first layer) | ||||||
| Lbs | 0 | 2000 | 6000 | 8000 | 10000 | |
| Line pull | Kg | 0 | 907 | 2722 | 3629 | 4536 |
| Line speed | M/min | 6,8 | 4,8 | 2,98 | 2,44 | 1,8 |
| Motor current | Amper | 80 | 130 | 230 | 290 | 350 |
| Line pull and cable capacity | |||||
| Layer of cable | 1 | 2 | 3 | 4 | |
| Lbs | 10000 | 8800 | 7800 | 6600 | |
| Rated line pull per layer | Kg | 4536 | 3990 | 3538 | 2994 |
| Cable capacity per layer | m | 6 | 13,2 | 22 | 28 |
