HRW-Series Seat Suspension

Swivel. Slide. Soften Every Shock.

The HRW-Series is a rugged, marine-grade seat suspension engineered to deliver premium comfort and control in rough conditions. Built-in swivel and slide functions offer optimal adjustability for skippers and crew who demand both performance and ergonomics on the water.

Built from heavy-duty materials, the HRW is not just about comfort — it’s about protecting sensitive backs and necks from impact, all while enhancing the look and feel of your boat.

Key Features & Specifications:

• Height range: 295–345 mm (11.5–14”)

• Height adjustment: 50 mm (2”)

• Adjustable pre-load: 50–130 kg (110–285 lb)

• Weight adjustment: On damper strut, with adjustment key attached to the base plate

• Swivel included: 360° rotation with 8 lock positions

• Slide included: Fore/aft movement of 120 mm (5”)

• Handles:

• Reachable while seated

• Can be mounted on either side during assembly

• Deck plate size: 375 × 225 mm (14.5 × 9”)

• Seat mount size: 330 × 315 mm (13 × 12.5”)

• Handle reach: 250 mm (10”) from centerline

• Installation: Quick and easy setup

• Build: Premium marine-grade materials

• Weight: 12.5 kg (27 lb)

• Standards: Complies with ABYC H-31 (Type AO)

• Mounting: One universal deck plate model

• Use case: Ideal for both fixed and adjustable seating setups
